Design Tools

TRACE® 3D Plus Load Design is the next evolution of the globally used and trusted TRACE® 700 Load Design software. This 3D design platform makes accurately sizing your HVAC systems faster and easier at any desired level of fidelity. We've taken our 50 years of HVAC systems design and software simulation knowledge and combined it with the U.S. Department of Energy's state-of-the-art EnergyPlus  simulation engine. The result is a platform that makes right sizing HVAC systems intuitive and visually dynamic with an easy to understand workflow that's less error prone. Try the new TRACE 3D Plus platform today and get accurate sizing results in a fraction of the time.

VariTrane Duct Designer streamlines duct design and improves calculation precision, letting you optimize your designs while obtaining a minimum pressure system. VariTrane Duct Designer enables you to organize the layout structure of your duct system and provides detailed engineering information on a section-by-section basis making revisions and updates easier.

The software is based on engineering data and procedures outlined in the ASHRAE Fundamentals Handbook. It includes tested data from ASHRAE Fitting database and from United McGill to provide the most accurate modeling possible.

Advantages:

• Improves calculation precision
• Organizes and optimizes designs
• Updates and revisions made simple
